MINISFORUM DEG1 eGPU Dock

🔹 Key Features & Specs

• Connection: OCuLink 4i (PCIe 4.0 ×4) uplink; a full-size PCIe ×16 downstream slot (electrically ×4)

• Compatibility: Supports full-height, full-length GPUs up to RTX 4090 or Radeon RX 7900 XTX

• Power Input: ATX or SFX PSU (mounts on dock); includes a 24-pin ATX connector and a “ForcePowerOn” LED switch

• Physical Dimensions: ~270 × 175 × 41 mm; approx. 880 g

• Design: Rugged aluminum body with open-air layout; signal amplifier to maintain stable PCIe 4.0 speeds

• Boot Sync: Auto power on/off with the host PC when using Minisforum devices

• Note: OCuLink is not hot-pluggable—you must power down to connect/disconnect
